The xtender multifunctional battery inverters offer an optimal management of all energy sources that can be found in offgrid, ongrid and hybrid systems. With 30+ years of experience from manufacturing power electronics in Switzerland, studer designed the xtender to provide reliable power to any application and to work with all types of battery technology. The xtender has a 10-year warranty.



Downloads



Outstanding efficiency and overload capacity

Self-consumption strategies, battery priority (or to renewable sources)



Perfect AC source management: peak power shaving, active load filtering



Compatible with AC coupling and all battery technologies (incl. lithium)



Advanced battery accessories

bts 01 Temperature sensor

bts 01

Temperature sensor

bsp Advanced battery processor (lead-acid)

bsp

Advanced battery processor (lead-acid)

xcom CAN Communication with lithium BMS

xcom CAN

Communication with lithium BMS

Display, datalogger, monitoring and communication

rcc 02/03 Configuration, display, datalogger

rcc 02/03

Configuration, display, datalogger

xcom LAN/GSM Remote monitoring (Portal & App)

xcom LAN/GSM

Remote monitoring (Portal & App)

xcom 232i/CAN/485i Communication bridges (openstuder)

xcom 232i/CAN/485i

Communication bridges (openstuder)

Compatible accessories

vario solar charge controller

vario

solar charge controller

ecf 01 Cooling fan for xts

ecf 01

Cooling fan for xts

xconnect Three-phase mounting frame for xth

xconnect

Three-phase mounting frame for xth

arm 02 External auxiliary contacts module

arm 02

External auxiliary contacts module

rcm 10 Remote control module

rcm 10

Remote control module

Technical data



xtender xtm

xtm 1500-12xtm 2000-12xtm 2400-24



Inverter

Nominal battery voltage (Input range)12 Vdc
(9.5 – 17 Vdc)		12 Vdc
(9.5 – 17 Vdc)		24 Vdc
(19 – 34 Vdc)
Continuous power @25°C1500 VA2000 VA2000 VA
Power 30 min. 25°C1500 VA2000 VA2400 VA
Power 5 sec. 25°C3.4 kVA4.8 kVA6 kVA
Output voltage and frequency(2)pure sine wave 230 Vac (± 2%)/120 Vac(3) and 45-65 Hz(3) ± 0.05% (crystal controlled)
Consumption OFF/Stand-by/ON1.2 / 1.4 / 8 W1.2 /1.4 / 10 W1.4 / 1.6 / 9 W
Maximum efficiency 93% (12Vdc battery voltage), 94% (24Vdc), 96% (48Vdc) | Maximum load up to short-circuit | Asymmetric load up to pcont. | Load detection (stand-by)(2) 2 to 25 W | Cos φ 0.1-1 | Harmonic distortion < 2 % | Overload and short-circuit protection automatic disconnection with 3 time restart attempt | Overheat protection warning before shut-off – with automatic restart

Battery charger

Maximum charging current(2)70 A100 A55 A
Charge characteristic(2) 6 steps: bulk, absorption, floating, equalization, reduced floating, periodic absorption | Temperature compensation(2) with bts 01 or bsp 500/1200 | Power factor correction (PFC) EN 61000-3-2

Transfer



Input voltage and frequency(2)150 to 265 Vac / 50 to 140 Vac(3) and 45 to 65 Hz
Input current max. (transfer relay) / Output current max.50 Aac / 56 Aac
Transfer time< 15 ms

General data

Weight15 kg18.5 kg16.2 kg
Dimensions h/w/l [mm]133 / 322 / 466 mm
Conformitylow voltage directive (LVD) 2014/35/EU: EN/IEC 62477-1, 62109-1, 62109-2, 62040-1, electromagnetic
compliance (EMC) directive 2014/30/EU: EN/IEC 61000-3-2, 61000-3-3, 61000-6-2, 61000-6-4, 62040-2
Multifunction contacts module arm 02 with 2 contacts in option, module rcm 10 with 1 remote entry in option | Protection index IP20 | Operating temperature range -20 to 55°C | Relative humidity 95 % without condensation | Ventilation oforced from 55°C | Acoustic level < 40 dB / < 45 dB (without/with ventilation)
xtm 2600-48xtm 3500-24xtm 4000-48



Inverter

Nominal battery voltage (Input range)48 Vdc
(38 – 60 Vdc)		24 Vdc
(19 – 34 Vdc)		48 Vdc
(38 – 60 Vdc)
Continuous power @25°C2000 VA3000 VA3500 VA
Power 30 min. 25°C2600 VA3500 VA4000 VA
Power 5 sec. 25°C6.5 kVA9 kVA10.5 kVA
Output voltage and frequency(2)pure sine wave 230 Vac (± 2%)/120 Vac(3) and 45-65 Hz(3) ± 0.05% (crystal controlled)
Consumption OFF/Stand-by/ON1.8 / 2 / 10 W1.4 / 1.6 / 12 W1.8 / 2.1 / 14 W
Maximum efficiency 93% (12Vdc battery voltage), 94% (24Vdc), 96% (48Vdc) | Maximum load up to short-circuit | Asymmetric load up to pcont. | Load detection (stand-by)(2) 2 to 25 W | Cos φ 0.1-1 | Harmonic distortion < 2 % | Overload and short-circuit protection automatic disconnection with 3 time restart attempt | Overheat protection warning before shut-off – with automatic restart

Battery charger

Maximum charging current(2)30 A90 A50 A
Charge characteristic(2) 6 steps: bulk, absorption, floating, equalization, reduced floating, periodic absorption | Temperature compensation(2) with bts 01 or bsp 500/1200 | Power factor correction (PFC) EN 61000-3-2

Transfer



Input voltage and frequency(2)150 to 265 Vac / 50 to 140 Vac(3) and 45 to 65 Hz
Input current max. (transfer relay) / Output current max.50 Aac / 56 Aac
Transfer time< 15 ms

General data

Weight16.2 kg21.2 kg22.9 kg
Dimensions h/w/l [mm]133 / 322 / 466 mm
Conformitylow voltage directive (LVD) 2014/35/EU: EN/IEC 62477-1, 62109-1, 62109-2, 62040-1, electromagnetic
compliance (EMC) directive 2014/30/EU: EN/IEC 61000-3-2, 61000-3-3, 61000-6-2, 61000-6-4, 62040-2
Multifunction contacts module arm 02 with 2 contacts in option, module rcm 10 with 1 remote entry in option | Protection index IP20 | Operating temperature range -20 to 55°C | Relative humidity 95 % without condensation | Ventilation oforced from 55°C | Acoustic level < 40 dB / < 45 dB (without/with ventilation)
(1) These features are valid only when using the cooling module ecf 01 | (2) Adjustable with the rcc 02/03 | (3) 120 V/60 Hz on request available for all xtender except xth 8000-48
Data may change without any notice.
